For many organizations, radios now play a critical role in ensuring everything from smooth daily operations to the coordinated response demanded by critical incidents. In a rapidly changing world, business, industry and public safety communications requirements have evolved from the basics of user-friendly operability to the innovative features enabled by the latest digital technologies. And setting the pace is KENWOOD’s NEXEDGE. NEXEDGE has been proven to be one of the most versatile communications systems available today, capable of satisfying a wide range of government and industry users. Offering conventional operation through to multi-site trunking, as well as paced migration from analog to digital, NEXEDGE is a perfect fit for any organization.

NEXEDGE employs the acclaimed NXDN digital air interface. This open standard is supported by many leading vendors, meaning that NEXEDGE systems are compatible with third-party products that conform to the mandatory features and standard optional features specified by the NXDN Forum.

And now, NEXEDGE steps into its 2nd chapter…

Building on this success, KENWOOD has developed NEXEDGE Generation 2 (Gen2). Supporting networks with as many as 1,000 sites, Gen2 delivers a significant boost in network scale and capability, yet also provides full compatibility with your current analog equipment. If you are looking to create a large-scale digital trunked network, NEXEDGE Gen2 has the features, capabilities and performance to satisfy all your needs.

Discover the power and versatility of NEXEDGE-abilities. Each of these key digital abilities has been developed specifically to perfectly align with your requirements for a robust and versatile digital network.

  • Intelligibility Superior Audio Quality
  • Reliability Fault Tolerant by Design
  • Flexibility Easy Configuration Changes
  • Scalability Expands to Meet Your Requirements
  • Manageability Fleet Management at Your Fingertips
  • Durability Engineered to Meet Stringent Military Specifications

NEXEDGE is one of the most versatile communications systems available today, capable of satisfying the communications needs for a wide range of utilities, transportation, manufacturing, industrial, and business users. With support for traditional conventional systems, conventional IP networks, and trunked networks—along with phased migration from analog to digital—NEXEDGE is a perfect fit for any organization.

Which NEXEDGE configuration is right for you?

Conventional
NEXEDGE conventional systems offer capabilities beyond analog conventional systems. With large unit ID and talk group ID capacity, operators can identify and segment different departmental groups and sub-groups on shared channels. Mixed Mode allows analog and digital fleets to share the same RF channel.

Conventional IP Network: Coverage
Conventional IP networks offer the ability to link two or more sites via IP network infrastructure to provide wide-area coverage across geographic areas. Subscriber zones on the network can be programmed for “Normal Channel Select” for traditional conventional operation or “Automatic Site Roam,” which allows NX radios to scan for site beacon signals that are transmitted periodically from all sites and automatically roam onto the site with the best signal strength. Which NEXEDGE configuration is right for you?

Conventional Simulcast: Coverage
Conventional Simulcast allows multiple geographically separated IP networked sites to transmit on the same frequency simultaneously, reducing the number of frequencies needed for the system and simplifying frequency coordination. This configuration is ideal for situations where limited frequencies are available or when improved in-building radio coverage is required. A simulcast controller located at one of the conventional sites synchronizes the system timing so that calls are transmitted simultaneously at all sites and subscriber radios receive the signal from multiple transmitters, allowing users to move between sites with no operator intervention.

NXDN Type-C Trunking Gen1: Capacity & Coverage
NXDN Type-C offers Control Channel-based trunking that automatically assigns channels for faster and more efficient use of spectrum. The NEXEDGE Type-C Generation 1 (Gen1) trunked system offers increased call capacity, enhanced call capabilities, improved security, and faster communications with less user interaction than conventional systems. The network option leverages the power of IP to create scalable networks over existing IT assets, private microwave, spread-spectrum links, or carrier services using standard Ethernet switches and routers. The 60,000 Group ID and Unit ID network capacity is sufficient for large organizations and multi-user system sharing.

NXDN Type-C Trunking Gen2: Capacity, Coverage & Control
NEXEDGE Gen2 is built on a server-based architecture that utilizes IP Network standards, designed to accommodate the need for expanded capacity. Gen2 provides more sites, centralized configuration, and enhanced management capabilities, with seamless roaming and compatibility with commercially available SNMP network monitoring applications. The System Controller Server is at the heart of the Gen2 infrastructure, acting as a media server for the connected sites and playing a key role in directing voice traffic throughout the radio network. Controllers can support up to 1,152 sites and 24 System Codes, linking multiple sites and channels for higher reliability at a lower cost. This allows operators to update and expand their NEXEDGE systems without any service disruption.

Standards-Based System

NEXEDGE operates on the widely supported NXDN open-standard Common Air Interface (CAI) for mobile communications. NXDN has been recognized by the International Telecommunications Union (ITU) as an International Open Standard. The NXDN Forum, a multi-faceted membership organization established in 2008, allows any manufacturer to develop products using the NXDN CAI without any fees, creating an open, competitive development environment free from unnecessary restrictions. Data applications such as AVL/mapping, Push-to-talk Over Cellular (PTToC), event logging, and messaging have become increasingly important management and operational requirements for utilities and industrial users. The KENWOOD Solution Developers program is a network of third party software and hardware vendors who work in close collaboration with JVCKENWOOD engineering, research, and development teams to provide data applications and gateways for NEXEDGE products. JVCKENWOOD also offers integration support to integrate NEXEDGE System solutions with third party data application providers.

  • Application Solutions Categories: AVL, GPS & Tracking
  • Event Logging & Voice Recording
  • Dispatch & Monitoring
  • PTToC Gateway Solutions
  • Email & Text Messaging

Futureproof Communication
The NXDN air interface is unique in that it is capable of fitting into both 12.5 kHz “narrow” and 6.25 kHz “very narrow” bandwidth channel operation to ensure frequency stability that exceeds all regulatory requirements in all bands.

The ability to operate in 6.25 kHz bandwidth mode offers:

  • Extended coverage — The high carrier-to-noise ratio of the narrower bandwidth allows for 30% wider coverage area compared to digital 12.5 kHz operation.
  • Extra protection from interference — Operating at 12.5 kHz has the potential to cause interference with a neighboring system; this problem is eliminated with a narrower bandwidth.
  • More available frequency licenses — 12.5 kHz frequency licenses are often more difficult to obtain than 6.25 kHz licenses, especially in large urban areas.

KENWOOD has spent more than 70 years perfecting sound. NEXEDGE radios possess renowned KENWOOD audio and noise-canceling technology for crisp, clear voice quality under any circumstances. The NX-3000 & 5000 series radios feature Active Noise Reduction (ANR), which uses a single microphone to perform complicated noise filtering that normally requires two microphones for processing. All KENWOOD radios are rugged, designed for extremes in temperature and daily use. All KENWOOD radios meet Mil-Spec 810 C, D, E, F and G and NEXEDGE portables also meet IP67 standard for dust and water immersion. KENWOOD portables are ideal for long shifts and constant use, with an ergonomically designed case that makes them easy to hold and up to 13.5 hours talk-time with the 2,000 mAh battery. The Intrinsically Safe (IS) models are an option for hazardous work environments with flammable materials.

Portables

Drawing on decades of KENWOOD engineering expertise, NEXEDGE portable radios stand out for their superb operating ease and impressive performance.

NX-5200/5300/5400

Mobiles

Offering intuitive operation with ergonomic controls and a high-visibility display, NEXEDGE mobile radios provide extensive FM/digital capabilities on the road.

NX-5700 / 5800 / 5900
NX-5700H

KENWOOD has spent more than 70 years perfecting sound. NEXEDGE radios possess renowned KENWOOD audio and noise-canceling technology for crisp, clear voice quality under any circumstances. The NX-3000 & 5000 series radios feature Active Noise Reduction (ANR), which uses a single microphone to perform complicated noise filtering that normally requires two microphones for processing.

All KENWOOD radios are rugged, designed for extremes in temperature and daily use. All KENWOOD radios meet Mil-Spec 810 C, D, E, F and G and NEXEDGE portables also meet IP67 standard for dust and water immersion. KENWOOD portables are ideal for long shifts and constant use, with an ergonomically designed case that makes them easy to hold and up to 13.5 hours talk-time with the 2,000 mAh battery. The Intrinsically Safe (IS) models are an option for hazardous work environments with flammable materials.

Portables
Drawing on decades of KENWOOD engineering expertise, NEXEDGE portable radios stand out for their superb operating ease and impressive performance.

NX-5200/5300/5400
NX-3200/3300
NX-3400/3420
NX-3220/3320
NX-200G/300G
NX-210G
NX-220/320
NX-410/411
NX-420
NX-240V/340U

Mobiles
Offering intuitive operation with ergonomic controls and a high-visibility display, NEXEDGE mobile radios provide extensive FM/digital capabilities on the road.

NX-5700 / 5800 / 5900
NX-5700H
NX-3720HG / 3820HG
NX-3920G / 3921HG
NX-700/800
NX-900/901
NX-720HG/820HG
NX-920G
NX-740HV/840HU

NXR-series repeaters are built tough for 24/7 reliability with a slim form factor to save space. With models supporting VHF, UHF, 800 MHz, and 900 MHz frequency bands, NEXEDGE repeaters support digital and FM analog operation on the same channel. The NXR-5000 series repeaters offer market-leading trunked capabilities with extensive data capabilities that provides support for everything from analog/digital conventional systems up to a highly sophisticated NEXEDGE Gen2 multi-site digital trunked network.

Base-Repeaters
Built tough for 24/7 reliability and fully supporting mixed FM/digital operation, the slim form factor of NEXEDGE repeaters save space.

NXR-5700 / 5800
NXR-5900/5901
NXR-710/810
NXR-900/901

Server-Based System Design
NEXEDGE Gen2 employs a server-based system architecture that offers both scalability and enhanced control capabilities. Hosted on a COTS rack-mounted server, the NEXEDGE Gen2 controllers and gateways can be connected anywhere on the network that supports sufficient bandwidth, with optional redundant configurations for additional reliability. Robust browser-based management tools allow system managers to remotely configure network settings from anywhere they have network access.

Network Manager System
The NEXEDGE Gen2 Network Manager System enables comprehensive monitoring of large-scale systems with multiple access points. In addition to NEXEDGE server and repeater monitoring, IP asset and network monitoring is also possible—this includes network traffic and load, network path, subscriber registration, latency, and event and error monitoring. Other functions include call log acquisition and analysis by group/site/call type, as well as reporting and alert settings.

IP Gateway for Consoles and Third-Party Equipment
The NEXEDGE Gen2 IP Gateway provides access to voice calls, GPS Data, and messaging. Each network can support 10 IP gateways and up to 100 consoles can link to a single IP gateway, allowing a single network to connect to a maximum of 1,000 consoles. Call recording and logging interfaces are also available.

Roaming Gateway for Multi-system Roaming
The NEXEDGE Gen2 Multi-system Roaming Gateway connects multiple Gen2 trunked systems to meet the needs of operators expanding to large-scale regional systems. Users can enjoy seamless auto-roaming among individual networks with different system codes, allowing you to expand coverage while maintaining control over your system.

Direct Frequency Assignment (DFA)
DFA allows you to easily and quickly keep your system up to date with new channels and sites by ensuring that as soon as new frequencies are added to the network, all equipment and subscriber units connected to the network are automatically notified.

Increased GPS Capacity
NEXEDGE Gen2 further enhances GPS operation to facilitate management of dynamic GPS updates. The System Controller is aware at all times how many GPS-equipped subscriber units are on duty, and when a new radio is registered, the controller assigns a reporting frame and traffic channel, updating over 750 units a minute. Improvements to the air protocol minimize data overhead, which maximizes traffic/data capacity, and reduces GPS data processing time.

Smart Design for KENWOOD Portables

You can seamlessly manage multiple batteries to extend battery lifetime and ensure that the batteries are optimally maintained. Using the Intelligent Battery Series, Intelligent Charger, and a PC installed with Battery Reader Software KAS-12, up to 60 Rapid Chargers can be chain-connected to the PC for status monitoring of batteries. Also, as an enhanced option of the KAS-12, up to 5,000 batteries can be managed, including storing the data acquired from a battery reader.

Intelligent Battery Series

KNB-L1
Li-Ion 7.4V/2000 mAh

KNB-L2
Li-Ion 7.4V/2600 mAh

KNB-L3
Li-Ion 7.4V/3400 mAh

KNB-N4
Ni-MH 7.2V/2500 mAh

Intelligent Charger
KSC-Y32 Battery conditions are displayed in illuminated color indicators on the charger, which are also displayed on a connected PC with the same color scheme. Red, yellow and green LEDs provide users with at-a-glance information for comprehensive battery management.
